Oct 10, 2010 Here are instructions on how to use Disk Utility to securely erase a hard drive connected internally or externally to your Mac. These instructions were written for Mac OS X 10.4 to 10.6. The process is very similar on older versions of Mac OS X, but the screens will look a. Oct 10, 2010 Here are instructions on how to use Disk Utility to securely erase a hard drive connected internally or externally to your Mac. These instructions were written for Mac OS X 10.4 to 10.6. The process is very similar on older versions of Mac OS X, but the screens will look a bit different. Jun 01, 2020 macOS Recovery makes it easy to reinstall the Mac operating system, even if you need to erase your startup disk first. All you need is a connection to the Internet. If a wireless network is available, you can choose it from the Wi-Fi menu, which is also available in macOS Recovery. I pressed command+r, went to disk utilities, selected my disk in the slot to the left, went to the erase tab. The 'erase' button is faded so I can't click it. Format is at Mac OS.
Erasing your disk: For most reasons to erase, including when reformatting a disk or selling, giving away, or trading in your Mac, you should erase your entire disk.
Erasing a volume on your disk: In other cases, such as when your disk contains multiple volumes (or partitions) and you don't want to erase them all, you can erase specific volumes on the disk.
Erasing a disk or volume permanently deletes all of its files. Before continuing, make sure that you have a backup of any files that you want to keep.
How to erase your disk
- Start up from macOS Recovery. Then select Disk Utility from the Utilities window and click Continue.
If you're not erasing the disk your Mac started up from, you don't need to start up from macOS Recovery: just open Disk Utility from the Utilities folder of your Applications folder. - Choose View > Show All Devices from the menu bar in Disk Utility. The sidebar now shows your disks (devices) and any containers and volumes within them. The disk your Mac started up from is at the top of the list. In this example, Apple SSD is the startup disk:
- Select the disk that you want to erase. Don't see your disk?
- Click Erase, then complete these items:
- Name: Type the name that you want the disk to have after you erase it.
- Format: Choose APFS or Mac OS Extended (Journaled). Disk Utility shows a compatible format by default.
- Scheme: Choose GUID Partition Map.
- Click Erase to begin erasing your disk and every container and volume within it. You might be asked to enter your Apple ID. Forgot your Apple ID?
- When done, quit Disk Utility.
- If you want your Mac to be able to start up from the disk you erased, reinstall macOS on the disk.
How to erase a volume on your disk
- Start up from macOS Recovery. Then select Disk Utility from the Utilities window and click Continue.
If you're not erasing the volume your Mac started up from, you don't need to start up from macOS Recovery: just open Disk Utility from the Utilities folder of your Applications folder. - In the sidebar of Disk Utility, select the volume that you want to erase. The volume your Mac started up from is named Macintosh HD, unless you changed its name. Don't see your volume?
- Click Erase, then complete these items:
- Name: Type the name that you want the volume to have after you erase it.
- Format: Choose APFS or Mac OS Extended (Journaled). Disk Utility shows a compatible format by default.
- If you see an Erase Volume Group button, the volume you selected is part of a volume group. In that case, you should erase the volume group. Otherwise, click Erase to erase just the selected volume. You might be asked to enter your Apple ID. Forgot your Apple ID?
- When done, quit Disk Utility.
- If you want your Mac to be able to start up from the volume you erased, reinstall macOS on that volume.
Reasons to erase
You can erase at any time, including in circumstances such as these:
- You want to permanently erase all content from your Mac and restore it to factory settings. This is one of the final steps before selling, giving away, or trading in your Mac.
- You're changing the format of a disk, such as from a PC format (FAT, ExFAT, or NTFS) to a Mac format (APFS or Mac OS Extended).
- You received a message that your disk isn't readable by this computer.
- You're trying to resolve a disk issue that Disk Utility can't repair.
- The macOS installer doesn't see your disk or can't install on it. For example, the installer might say that your disk isn't formatted correctly, isn't using a GUID partition scheme, contains a newer version of the operating system, or can't be used to start up your computer.
- The macOS installer says that you may not install to this volume because it is part of an Apple RAID.
About APFS and Mac OS Extended
Disk Utility in macOS High Sierra or later can erase using either the newer APFS (Apple File System) format or the older Mac OS Extended format, and it automatically chooses a compatible format for you.
How to choose between APFS and Mac OS Extended
Disk Utility tries to detect the type of storage and show the appropriate format in the Format menu. If it can't, it chooses Mac OS Extended, which works with all versions of macOS. If you want to change the format, answer these questions:
- Are you formatting the disk that came built into your Mac?
If the built-in disk came APFS-formatted, Disk Utility suggests APFS. Don't change it to Mac OS Extended. - Are you about to install macOS High Sierra or later for the first time on the disk?
If you need to erase your disk before installing High Sierra or later for the first time on that disk, choose Mac OS Extended (Journaled). During installation, the macOS installer decides whether to automatically convert to APFS—without erasing your files. - Are you preparing a Time Machine backup disk or bootable installer?
Choose Mac OS Extended (Journaled) for any disk that you plan to use as a Time Machine backup disk or as a bootable installer. - Will you be using the disk with another Mac?
If the other Mac isn't using macOS High Sierra or later, choose Mac OS Extended (Journaled). Earlier versions of macOS don't work with APFS-formatted volumes.
How to identify the format currently in use
If you want to know which format is currently in use, use any of these methods:
- Select the volume in the Disk Utility sidebar, then check the information shown on the right. For more detail, choose File > Get Info from the Disk Utility menu bar.
- Open System Information and select Storage in the sidebar. The File System column on the right shows the format of each volume.
- Select the volume in the Finder, then choose File > Get Info from the menu bar. The Get Info window shows the Format of that volume.
If your disk or volume doesn't appear, or the erase fails
- Shut down your Mac, then unplug all nonessential devices from your Mac.
- If you're erasing an external drive, make sure that it's connected directly to your Mac using a cable that you know is good. Then turn the drive off and back on.
- If your disk or volume still doesn't appear in Disk Utility, or Disk Utility reports that the erase process failed, your disk or Mac might need service. If you need help, please contact Apple Support.
Learn more
- If you can't start up from macOS Recovery, you can use a different startup disk instead.
- If Disk Utility shows a Security Options button in the Erase window, you can click that button to choose between a faster (but less secure) erase and a slower (but more secure) erase. Some older versions of Disk Utility offer the option to zero all data instead. These secure-erase options aren't offered or needed for solid-state drives (SSDs) and flash storage.
Hello and welcome to my User Tip
You need to erase and install 10.6 Snow Leopard, I will show you how to do this.
If your here because you upgraded to 10.7 Lion and want to go back to 10.6 Snow Leopard you need to see this thread.
A little more preparation is in order to make sure your files work in Snow Leopard.
If your here because you have a problem and you think erasing and reinstalling is going to solve it, it most certainly will, but you might not need to go this far and you might want to recover data off the non-booting drive first.
If your here because you want to secure erase data better than writing Zero's acorss the selected hard drive or partition (good enough for most folks), this tip doesn't cover that, see this one then come back here afterwards.
Use the correct 10.6 disk to install Snow Leopard
Use the free MacTracker to find your model of Mac, you can gleam the model from your Apple Menu > About this Mac > More information and look for something like 'MacBook Pro 3,1' and punch that into MacTracker.
Mac Os 10.6 8 Erase Hard Drive Completely
There are basically two types of 10.6 install disks, the gray or black machine specfic ones that came with a new Mac (free iLife) or the 10.6.3 retail disks (no free iLife).
You can't use another model of Mac's 10.6 machine specific disks with another Mac, there isn't hardware drivers on those disks that will work on other Mac's.
If a Mac came pre-installed or from the factory with 10.6.3 or later, you cannot use the 10.6.3 retail disks (no iLife) from Apple online, you have to call Apple for your 10.6.3+ machine specific install disks (free iLife included)
Ready to erase and install Snow Leopard?
Your data will be gone after this and not recoverable what so ever, don't come crying later that you missed something.
You might want to take this chance to export web browser bookmarks, grab product keys or even clone the old 10.6 drive before you erase it.
Unmount and disconnect all other drives. No mistakes. Here we go.
Make sure the bottom of the disk is clean, use a very soft cloth and a tiny dab of rubbing alcohol and polish to a shine. 🙂
Hold c (or option/alt key) down on a wired or built in keyboard, and boot the machine, off the 10.6 installer disk (or hold option key boot off the 10.6 clone drive) and under the Utilities menu (folder) is Disk Utility.
To erase the entire drive of all partitions:
Select the entire internal boot drive on the far left, it will have the drive makers name and size.
Do not select the indented names, those are just partitions on the drive, you need to erase the entire drive to catch everything, rebuild the GUID partition table and the hidden EFI partition.
If your here to revert your machine to Snow Leopard from 10.7 or later, then make sure to select the ENTIRE drive on the left in Disk Uitlity.
To erase just the OS X partition leaving others like Bootcamp etc.
Select the indented name of the OS X partition instead, however it will not cure problems in the hidden EFI or GUID partition table. Do not do if your reverting to Snow Leopard from a later OS X verison, because 10.7 and later OS X verisons alter the GUID and add a Recovery HD partition that needs to be removed before 10.6 is reinstalled. This is so later when you need to use the 10.6 disk to repair the drive, it knows what is on the boot drive.
Click Erase > Security option > Zero All Data (will map off any failing sectors) go watch a movie, it takes a bit and improves your hard drives reliability and read speeds. (SSD no need zero, just erase). Trust me this works wonders!
If the Disk Utility > Zero Erase fails or hangs, the drive has run out of spare sectors and is worthless, it will have to be replaced, better you found out now than later with your data on it.
Check under Partition: Options that you have a GUID and Format: OS X Extended Journaled, if not change it to those and apply.
Quit Disk Utility. You will be back into the 10.6 installer.
Fresh installing Snow Leopard 10.6
If your using your option key bootable 10.6 clone, use the cloning software to reverse clone 10.6 onto the internal drive then return your files from the storage drive. Your done, see you later.
Now for you who just erased the internal drive via the 10.6 disk and need to install fresh.
'Fresh' means no possibly corrupt TimeMachine, Migration Assistant, or clone restores. New OS X, programs and only vetted files returned.
Performance types swear by this method as it allows the leaving of previous junk, malware, old files etc behind. Trim and speedy.
1: Quit Disk Utility and install 10.6. from the installer disk.
Reboot, setup and use the same user name as before. (different password ok) Why?, because you can place your user files from backup right on in and your iTunes playlists, permissions etc work. Unless you don't want to use the same name, then you lose the playlists and have to recreate them, change the permissions for files.
2: Use Software Update to get up to 10.6.8 fully, repeat until clear.. This is very important to do or you'll have problems later.
3: Install Rosetta for your PowerPC based programs
Insert the Mac OS X installation disc that came with your computer or with your Mac OS X retail package.
Double-click the Optional Installs folder, and then double-click the Optional Installs package.
A package has an icon that looks like an open box.
Follow the onscreen instructions. Select the disk where you want to install Rosetta and click Continue.
Select the checkbox next to Rosetta, click Continue, and then click Install.
4: Install all third party programs from fresh original sources and compatible with 10.6.8
If by chance you get a hang upon reboot after installing third party software, hold the shift key down upon booting and update or remove the problem software, you will know, you just installed it. 🙂
If you had 10.5 previously on the machine, you'll notice your iLife is missing with the 10.6 install. This is because the 10.6.3 disk doesn't have it, only the machine specific disks do that come with the Mac when it was new.
You can either buy the 10.6 iLife from Apple or use Pacifist from CharlesSoft to extract the 10.5 versions from the 10.5 install disks. You paid for it so it's yours.
5: Once you have all your third party software installed (as best as you can of course) next is to hook up your storage drive.
Return the contents of those user files folders: Music, Pictures, Movies, Documents etc (not Library) to their respective folders in each account
Apple support doc on installing 10.6 again
Hard drive performance tip
If you installed exactly in the order as I have outlined above (1, 2,3,4), and keep your boot drive below 50% filled, it will operate at peak performance forever until it dies, or you damage it by moving it around while it's operating.
Your hard drive performance will suffer greatly the more OS X boot partition data is written on the second 50% of the drive, even if you remove some to get under 50%.
If there is any data on the second 50% of the drive, the heads have to travel there to get it, use the smaller sectors and that slows read/write performance on hard drives (SSD no need to worry).
Whatever you do, don't go past 80% filled on boot drives on Mac's as your pressing your performance and stability luck.
Problems installing?
1: Hold the power button down to hard shutdown.
2: Hold the option key and trackpad button/wired left mouse button down (wired or built in keyboard might be needed) and boot the machine.
3: The disk hopefully should pop out, if not when you get to Startup Manager, keep pressing eject on the keyboard.
4: Take some rubbing alcohol (a tiny bit) on a soft clean cloth and polish the bottom of the disk, when dry and blemish free, stick it in and when it appears, click the arrow key to boot from it.
5: Review your secure erase procedures here to make sure your not leaving data
6: Try to reinstall 10.6 again
7: If that fails, call Apple and tell them what Mac you have and see if you require MACHINE SPECIFIC Snow Leopard install disks. (10.6.4 -10.6.8) These disks also include the free iLife suite on them.
The 10.6 white retail disks sold online are 10.6.3 and won't work in your machine due to a lack of more recent hardware drivers not present on those disks also they don't contain the free iLife suite.
Apple might also have 10.6.0 - 10.6.3 machine disks as well if you need the free iLife, but they could take longer to come than the 10.6.3 white retail disk.
8: After install, just hard shutdown and it will boot to the 'Welcome' video for the next owner.
Mac Os X 10.6.8 Erase Hard Drive
Advanced options
9: If Apple is going to take too long to send you disks or won't, there is a option to create a image of the bad disk and burn a new one on another Mac (possibly on a PC too) as a ISO image.
Sometimes when the read and burn occurs, errors are repaired and the new image will work when the old one won't.
10: Another option is to create a Snow Leopard boot USB from the 10.6 disk, then boot and install with that.
Mac Os 10.6 8 Erase Hard Drive Download
Mac Os 10.6 8 Erase Hard Drive On Macbook Pro
That's it, enjoy. 🙂
